Vauxhall Astra Van

Workshop data. Confirm against the vehicle placard.

All makes › Vauxhall › Astra Van › 2002

Cold pressures. Final-tighten wheel nuts with a calibrated torque wrench, never an impact gun. Re-check after 25–50 miles.

Wheel nut torque · 2002

110 Nm

175/70R14, 185/65R14, 185/70R14, 195/60R15, 205/50R16

1 2 3 4
4 bolts
1 4 2 5 3
5 bolts
1 2 6 4 3 5
6 bolts

Use the star / cross order that matches the wheel. Start fasteners by hand. Seat the wheel flush on the hub before final torque. Recheck after 25–50 miles. Confirm against the vehicle placard and handbook.

Pressures Torque Placard Location

Workshop checks

When to torque: every time a wheel is off — tyres, punctures, seasonal swap, brakes.

Seat first: the wheel must sit flush on the hub. Dirt or rust under the wheel means the wrench number is meaningless.

Match the seat: conical, ball/radius and flat/washer seats are not interchangeable. Thread size alone is not enough.

Recheck: after 25–50 miles check the same figure again. Do not add extra Nm.

Conicaltapered cone — angle must match the wheel
Ball / radiusrounded seat — common on some OEM alloys
Flat / washerflat clamp, often with a shank and washer

Pressures

TyreNormal F/RLaden F/REco F/RTorque
175/70R14 31 PSI / 29 PSI — — 110 Nm
185/65R14 33 PSI / 30 PSI — — 110 Nm
185/70R14 30 PSI / 27 PSI — — 110 Nm
195/60R15 31 PSI / 29 PSI — — 110 Nm
205/50R16 31 PSI / 29 PSI — — 110 Nm

Vehicle

Vauxhall Astra Van
2002 Vauxhall Astra Van
