Fiat Doblo

Workshop data. Confirm against the vehicle placard.

All makes › Fiat › Doblo › 2011

Cold pressures. Final-tighten wheel nuts with a calibrated torque wrench, never an impact gun. Re-check after 25–50 miles.

Wheel nut torque · 2011

100 Nm

195/60R16, 195/65R15

1 2 3 4
4 bolts
1 4 2 5 3
5 bolts
1 2 6 4 3 5
6 bolts

Use the star / cross order that matches the wheel. Start fasteners by hand. Seat the wheel flush on the hub before final torque. Recheck after 25–50 miles. Confirm against the vehicle placard and handbook.

Pressures Torque Placard Location

Workshop checks

When to torque: every time a wheel is off — tyres, punctures, seasonal swap, brakes.

Seat first: the wheel must sit flush on the hub. Dirt or rust under the wheel means the wrench number is meaningless.

Match the seat: conical, ball/radius and flat/washer seats are not interchangeable. Thread size alone is not enough.

Recheck: after 25–50 miles check the same figure again. Do not add extra Nm.

Conicaltapered cone — angle must match the wheel
Ball / radiusrounded seat — common on some OEM alloys
Flat / washerflat clamp, often with a shank and washer

Pressures

TyreNormal F/RLaden F/REco F/RTorque
195/60R16 39 PSI / 39 PSI 39 PSI / 39 PSI — 100 Nm
195/65R15 35 PSI / 35 PSI 35 PSI / 35 PSI — 100 Nm

Vehicle

Fiat Doblo
2011 Fiat Doblo

Fitment specs

2000 Bolt Pattern: 5x98. Recorded centre bore (mm): 58.1.Wheel offset (ET)Recorded offset (ET mm):
2000 Bolt Pattern: 5x98. Recorded centre bore (mm): 58.1.Wheel offset (ET)Recorded offset (ET mm):
2000 Bolt Pattern: 5x98. Recorded centre bore (mm): 58.1.Wheel offset (ET)Recorded offset (ET mm):
2000 Bolt Pattern: 5x98. Recorded centre bore (mm): 58.1.Wheel offset (ET)Recorded offset (ET mm):
2000 Centre Bore: 58.110 - 24Tyre sizes195/65R15195/60R16PCD: 5x98Front Offset: 37Rear Offset: 37C
2000 Centre Bore: 58.110 - 24Tyre sizes195/65R15195/60R16PCD: 5x98Front Offset: 37Rear Offset: 37C
2000 Centre Bore: 58.110 - 24Tyre sizes195/65R15195/60R16PCD: 5x98Front Offset: 37Rear Offset: 37C
2000 Centre Bore: 58.110 - 24Tyre sizes195/65R15195/60R16PCD: 5x98Front Offset: 37Rear Offset: 37C
2000 Offset: centre-bore/","name":"Fiat Doblo Wheel Fitment, PCD, Offset & Centre Bore | Pure
2000 Offset: 37Rear Offset: 37Centre Bore: 58.110 - 24Tyre sizes195/65R15195/60R16PCD: 5x98Fr
2000 Offset: 37Rear Offset: 37Centre Bore: 58.110 - 24Tyre sizes195/65R15195/60R16PCD: 5x98Fr
2000 Offset: 37Rear Offset: 37Centre Bore: 58.110 - 24Tyre sizes195/65R15195/60R16PCD: 5x98Fr
2000 PCD: offset-centre-bore/","name":"Fiat Doblo Wheel Fitment, PCD, Offset & Centre Bore
2000 PCD: 5x98Front Offset: 37Rear Offset: 37Centre Bore: 58.110 - 24Tyre sizes195/65R1519
2000 PCD: 5x98Front Offset: 37Rear Offset: 37Centre Bore: 58.110 - 24Tyre sizes195/65R1519
2000 PCD: 5x98Front Offset: 37Rear Offset: 37Centre Bore: 58.110 - 24Tyre sizes195/65R1519
2010 Centre bore: 58.1
2010 Front offset: 37
2010 PCD: 5x98
2010 Rear offset: 37
2010 Centre bore: 58.1
2010 Front offset: 37
2010 PCD: 5x98
2010 Rear offset: 37
2010 Centre bore: 58.1
2010 Front offset: 37
2010 PCD: 5x98
2010 Rear offset: 37
2011 Centre bore: 58.1
2011 Front offset: 37
2011 PCD: 5x98
2011 Rear offset: 37
2011 Centre bore: 58.1
2011 Front offset: 37
2011 PCD: 5x98
2011 Rear offset: 37
2012 Centre bore: 58.1
2012 Front offset: 37
2012 PCD: 5x98
2012 Rear offset: 37
2012 Centre bore: 58.1
2012 Front offset: 37
2012 PCD: 5x98
2012 Rear offset: 37
2013 Centre bore: 58.1
2013 Front offset: 37
2013 PCD: 5x98
2013 Rear offset: 37
2013 Centre bore: 58.1
2013 Front offset: 37
2013 PCD: 5x98
2013 Rear offset: 37
2014 Centre bore: 58.1
2014 Front offset: 37
2014 PCD: 5x98
2014 Rear offset: 37
2014 Centre bore: 58.1
2014 Front offset: 37
2014 PCD: 5x98
2014 Rear offset: 37
