Fiat Albea

All makes › Fiat › Albea › 2004

Cold pressures. Final-tighten wheel nuts with a calibrated torque wrench, never an impact gun. Re-check after 25–50 miles.

Wheel nut torque · 2004

120 Nm

165/80R13, 175/65R14

4 bolts

5 bolts

6 bolts

Use the star / cross order that matches the wheel. Start fasteners by hand. Seat the wheel flush on the hub before final torque. Recheck after 25–50 miles. Confirm against the vehicle placard and handbook.

Pressures Torque Placard Location

Workshop checks

When to torque: every time a wheel is off — tyres, punctures, seasonal swap, brakes.

Seat first: the wheel must sit flush on the hub. Dirt or rust under the wheel means the wrench number is meaningless.

Match the seat: conical, ball/radius and flat/washer seats are not interchangeable. Thread size alone is not enough.

Recheck: after 25–50 miles check the same figure again. Do not add extra Nm.

Conicaltapered cone — angle must match the wheel

Ball / radiusrounded seat — common on some OEM alloys

Flat / washerflat clamp, often with a shank and washer

Pressures

Tyre	Normal F/R	Laden F/R	Eco F/R	Torque
165/80R13	31 PSI / 30 PSI	—	—	120 Nm
175/65R14	31 PSI / 30 PSI	—	—	120 Nm

Vehicle

Fitment specs

2002 Bolt Pattern: 4x98. Recorded centre bore (mm): 58.1.Wheel offset (ET)Recorded offset (ET mm):
2002 Bolt Pattern: 4x98. Recorded centre bore (mm): 58.1.Wheel offset (ET)Recorded offset (ET mm):
2002 Bolt Pattern: 4x98. Recorded centre bore (mm): 58.1.Wheel offset (ET)Recorded offset (ET mm):
2002 Bolt Pattern: 4x98. Recorded centre bore (mm): 58.1.Wheel offset (ET)Recorded offset (ET mm):
2002 Centre Bore: 58.1Sponsored(adsbygoogle=window.adsbygoogle||[]).push({});Understanding wheel f
2002 Centre Bore: 58.1SponsoredUnderstanding wheel fitment measurements: Fiat AlbeaPCD and centre
2002 Centre Bore: 58.1SponsoredUnderstanding wheel fitment measurements: Fiat AlbeaPCD and centre
2002 Centre Bore: 58.1SponsoredUnderstanding wheel fitment measurements: Fiat AlbeaPCD and centre
2002 Offset: centre-bore/","name":"Fiat Albea Wheel Fitment, PCD, Offset & Centre Bore | Pure
2002 Offset: 40Rear Offset: 40Centre Bore: 58.1SponsoredUnderstanding wheel fitment measureme
2002 Offset: 40Rear Offset: 40Centre Bore: 58.1SponsoredUnderstanding wheel fitment measureme
2002 Offset: 40Rear Offset: 40Centre Bore: 58.1SponsoredUnderstanding wheel fitment measureme
2002 PCD: offset-centre-bore/","name":"Fiat Albea Wheel Fitment, PCD, Offset & Centre Bore
2002 PCD: 4x98Front Offset: 40Rear Offset: 40Centre Bore: 58.1SponsoredUnderstanding wheel
2002 PCD: 4x98Front Offset: 40Rear Offset: 40Centre Bore: 58.1SponsoredUnderstanding wheel
2002 PCD: 4x98Front Offset: 40Rear Offset: 40Centre Bore: 58.1SponsoredUnderstanding wheel
2002 Centre bore: 58.1
2002 Front offset: 40
2002 PCD: 4x98
2002 Rear offset: 40
2002 Centre bore: 58.1
2002 Front offset: 40
2002 PCD: 4x98
2002 Rear offset: 40
2003 Centre bore: 58.1
2003 Front offset: 40
2003 PCD: 4x98
2003 Rear offset: 40
2003 Centre bore: 58.1
2003 Front offset: 40
2003 PCD: 4x98
2003 Rear offset: 40
2004 Centre bore: 58.1
2004 Front offset: 40
2004 PCD: 4x98
2004 Rear offset: 40
2004 Centre bore: 58.1
2004 Front offset: 40
2004 PCD: 4x98
2004 Rear offset: 40
2005 Centre bore: 58.1
2005 Front offset: 40
2005 PCD: 4x98
2005 Rear offset: 40
2005 Centre bore: 58.1
2005 Front offset: 40
2005 PCD: 4x98
2005 Rear offset: 40
2006 Centre bore: 58.1
2006 Front offset: 40
2006 PCD: 4x98
2006 Rear offset: 40
2006 Centre bore: 58.1
2006 Front offset: 40
2006 PCD: 4x98
2006 Rear offset: 40
2007 Centre bore: 58.1
2007 Front offset: 40
2007 PCD: 4x98
2007 Rear offset: 40
